OEM Vacuum Induction Furnace Horizontal Industrial Vacuum Oven 2T-35T Stable
Negotiable
MOQ
Negotiable
Price
OEM Vacuum Induction Furnace Horizontal Industrial Vacuum Oven 2T-35T Stable
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: CHINA
Brand Name: OEM
Certification: CE Certification
Model Number: OEM
High Light:

industrial vacuum furnace

,

high vacuum furnace

Payment & Shipping Terms
Packaging Details: Carton, pallet, wooden case or according to customer's package requirements
Delivery Time: 30 working days
Payment Terms: 30% deposit + 70% T/T before shipping
Supply Ability: 20 sets per month
Specifications
NAME: Vacuum Induction Furnace
Type: Horizontal
Weight: 2T-35T
OEM Service: Acceptable
Structure: Horizontal Type, Vertical Type
Usage: Sintering Furnace
Product Description

OEM Vacuum Induction Furnace , Horizontal Industrial Vacuum Oven 2T-35T



Vacuum Induction Furnace Description


Industrial sintering furnace is applied for powder metallurgy, such as stainless steel sintering (injection and silk screen) and magnetic material, such as aluminumalnico and samarium cobalt.


NameParameter
Vacuum sintering furnacesintering process, debinding, dewaxing
ModelHorizontal, Vertical
Ultimate vacuumCustom made
Pressure rising rate0.5pa/h
Max temperatureCustom made
Temperature uniformity±3℃ / ±5℃
Heating powerCustom made
Temperature control methodIntelligent programmable temp controller
Control methodPLC auto/manual interlock protection
Max gas charging pressure (absolute pressure)Custom made




Specification



Main technical data of 1450 degree vacuum sintering furnace

Effective working
dimension
(mm)

Max temperature
(C)

Ultimate pressure
(pa)

Pressure
rising rate
(pa/h)

Temperature
Uniformity
(C)

600x500x120014502x10-30.5±3
800x300x120014502x10-30.5±3
800x800x120014502x10-30.5±3
900x900x150014502x10-30.5±3
custom made1450custom madecustom madecustom made
