Uniform Heating Vacuum Sintering Furnace With Advanced Automation Control

Negotiable
MOQ
Negotiable
Price
Uniform Heating Vacuum Sintering Furnace With Advanced Automation Control
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Vacuum Sintering Furnace
Heating: Uniform Heating
Power: 250/400/500/800
Heating Method: Resistance Heating
Rated Power Supply Voltage: 380V
Control: Advanced Automation Control
High Light:

vacuum tempering furnace

,

high vacuum furnace

Basic Infomation
Place of Origin: CHINA
Brand Name: OEM
Certification: CE Certification
Model Number: OEM
Payment & Shipping Terms
Packaging Details: Carton, pallet, wooden case or according to customer's package requirements
Delivery Time: 30 working days
Payment Terms: 30% deposit + 70% T/T before shipping
Supply Ability: 20 sets per month
Product Description

Uniform Heating Vacuum Sintering Furnace With Advanced Automation Control





Vacuum Sintering Furnace Application :


Used for high temperature sintering of carbon fiber, carbon material, C/C composite material, metal powder products, photoelectric components, hard alloys, magnetic alloys, ceramic powder materials, and other materials, and has dewaxing function.



Vacuum Sintering Furnace Features:


Uniform heating, reliable insulation and temperature measurement;
Reasonable heating structure, high-quality materials to ensure uniformity of furnace temperature under vacuum;
The use of domestic and international brand temperature measuring components to ensure the accuracy of temperature measurement.



Vacuum Sintering Furnace applicability


Single chamber, vertical structure, compact and reasonable equipment layout, small footprint;
Advanced automatic control, comprehensive PLC water, electricity, gas automatic control and protection system, PLC realizes safety chain, with sound and light alarms such as over temperature, sensor break, water pressure, furnace overpressure, water flow, high water temperature;
energy saving:
Resistive heating within 2000 °C, high temperature control accuracy, no noise, no pollution to the power grid, high energy utilization;
The low temperature section and the high temperature section are respectively controlled by different temperature control elements and automatically switched;
The high-temperature section is cooled by natural cooling, and the low-temperature section can be cooled by charging positive pressure inert gas.





Volume (L) 423 1250 2387 5086
Rated temperature (°C) 2000 2000 2000 2000
Limit temperature (°C) 2100 2100 2100 2100
Effective heating zone (mm) Φ600X1500 Φ1000X1600 Φ1300X1800 Φ1800X2000
Power (KW) 250 400 500 800
Temperature control method Japanese island electric thermostat
heating method Resistance heating
Vacuum system Spool valve vacuum pump + Roots vacuum pump (vacuum degree requirements high with oil diffusion pump)
Sintering atmosphere N²,Ar²and other gases
Rated power supply voltage (V) 380
Rated heating voltage (V) According to the design, the pre-furnace transformer is configured.
Vacuum limit (Pa) 6X10ˉ²(vacuum cold state)
