Medium Frequency Large Melting Furnace , Metal Aluminium Scrap Melting Equipment

Negotiable
MOQ
Negotiable
Price
Medium Frequency Large Melting Furnace , Metal Aluminium Scrap Melting Equipment
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Induction Melting Furnace
Rated Power: 100kw
Rated Capacity: 0.1T
Voltage: 380v, 50/60HZ
MF Frequency: 2000HZ
Medium Voltage: 750v Phase
DC Voltage: 500V Phase
DC Current: 200A Phase
Rated Temperature: 1600°c
Color: Customizable
Melting Material: Gold, Silver, Copper, Iron And Aluminum Etc
Control Cabinet Size: 1450*1000*850cm
Furnace Size: 1350*980*860cm
Control Cabinet Weight: 600kg
Furnace Weight: 300kg
Highlight:

steel melting furnace

,

steel induction furnace

Basic Infomation
Place of Origin: CHINA
Brand Name: OEM
Certification: CE Certification
Model Number: OEM
Payment & Shipping Terms
Packaging Details: Carton, pallet, wooden case or according to customer's package requirements
Delivery Time: 30 working days
Payment Terms: 30% deposit + 70% T/T before shipping
Supply Ability: 20 sets per month
Product Description

Medium Frequency metal aluminium induction scrap melting furnace



 1. Brief Introduction of 0.1Ton Medium Frequency Induction Melting Furnace:
 Medium Frequency melting induction furnace, aluminum shell mechanical tilt, is for melting cast steel, cast iron, stainless steel, copper, aluminum and other metals or its alloy.It is particularly suited to small and medium-size enterprises, or as Precision Casting Material Test.


2. Technical Parameter of Large Induction Melting Furnace:

Rated Power 100kw
Rated Capacity 0.1T
Matching transformer's capacity 150KVA
Voltage 380V, 50/60HZ
MF Frequency 2000HZ
Medium Voltage 750V Phase
DC Voltage 500V Phase
DC Current 200A Phase
Rated Temperature 1600°C
Closed Loop Water Cooling Tower LSN-10B



3. Large Induction Melting Furnace Application:

(1) iron, pig iron, cast iron;

(2) steel, stainless steel, cast steel, carbon steel and bearing steel;

(3) gold, silver, platinum;

(4) copper, brass, bronze;

(5) aluminum, aluminum alloy;

(6) zinc, lead, tin, magnesium, nickel, titanium.


Medium Frequency Large Melting Furnace , Metal Aluminium Scrap Melting Equipment 0


4. Advantage of Large Induction Melting Furnace :
1. Frequency-sweep zero voltage start, high success rate, no shock;
2. Automatic resistance adjustment, permanent power output, 10-20% energy saved in comparison with domestic traditional machine of the type;
3. Auto phase sequence adaptation, free of synchronization;
4. Good performance in reload staring, auto recovery;
5. Highly integrated in controlling circuit, free of use of high-rate starter and relay loop, fairly low failure rate;
6. Wholly digital design, strong in anti-interference, no temperature shift when in continuous working;
7. Multi-protection functions (for over current, over voltage, insufficient water pressure, power failure, or phase absence), and mishandling will not cause damage to machine.

As for packing of induction melting furnace:

wooden / plywood cases and the furnace is packed with wrapping film and the case is filled with foam,for waterproof and shockproof.

As for shipping of induction melting furnace:

1. If you have a shipper in China, we can send the machines to him or her for free.

2. If you want us to send the machines to you directly, we can send them to any main port of China promptly.
