Eco - Friendly Titanium Melting Furnace / Metal Melting Furnace 380v
Titanium Melting Furnace mainly used for pyrolysis, melting, analysis and production ceramics, metallurgy, electronics, machinery, chemical, glass, refractories material,etc. it can be used as the vacuum heat treatment furnace,vacuum sintering furnace,vauum melting furnace,vacuum quenching furnace,vacuum annealing furnace,vacuum tempering furnace,vacuum melting furnace. This type equipment is also suitable for institutions of higher learning and laboratory of scientific research institute and industrial and mining enterprises for developing new material, special materials, construction materials and so on.
| Volume (L) | 484 |
| Rated Temperature (°C) | 2400 |
| Limit Temperature (°C) | 2450 |
| Effective Heating Zone (Mm) | 550X550X1600 |
| Power (KW) | 350 |
| Frequency (HZ) | 1000 |
| Temperature Control Method | Japanese island electric thermostat |
| Heating Method | Induction heating |
| Vacuum System | Spool valve vacuum pump + Roots vacuum pump |
| Sintering Atmosphere | N2, Ar2 and other gases |
| Rated Power Supply Voltage (V) | 380 |
| Rated Heating Voltage (V) | According to the design, configure the transformer |
| Vacuum Limit (Pa) | 40 (vacuum cold state) |
