Industrial Vacuum Lab Oven High Temperature Easy Operation High Efficiency

Industrial Vacuum Lab Oven High Temperature Easy Operation High Efficiency
Features Gallery Product Description Request A Quote
Name: Horizontal Vacuum Furnace
Style: Horizontal
Classification: Laboratory Heating Equipment
Fuel: Furnace
Applications: Industrial
High Light:

heating and drying ovens


high temperature drying oven

Basic Infomation
Place of Origin: CHINA
Brand Name: OEM
Certification: CE Certification
Model Number: OEM
Payment & Shipping Terms
Packaging Details: Carton, pallet, wooden case or according to customer's package requirements
Delivery Time: 30 working days
Payment Terms: 30% deposit + 70% T/T before shipping
Supply Ability: 20 sets per month
Product Description

Vacuum Atmosphere Furnace , High Temperature Vacuum Furnace

Product Description


 high temperature vacuum furnace is mainly used in sintering cemented carbides, stainless steel line molding, stainless steel fiber, magnetic materials,and ceramic materials,and it also can be used in power metallurgy, refractory metals
and magnetic material industry.We can sinter super hard, alloy,tungsten, titanium, copper, tantalum,stainless steel and rare-earth permanent magnetic material. Since the heater symmetrical distribute along the vacuum chamber, and temperature uniformity is high,you can actualize semi-automatic and automatic control according to your demands.


1. Maximum energy efficiency is achieved by surrounding chamber thermal-efficient alumina fiber ceramic insulation. 2. Heavy duty double layer structure with cooling fan. Lower teperature in outside case.
3. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).
4. Power control with 30 segments programmable.



Max. temperature 1700ºC 1400ºC 1200ºC
Working temperature 1600ºC 1300ºC 1100ºC
Temperature accuracy +/-1ºC
Heating rate 0-20C/min 0 -20C/min 0-30C/min
standard chamber size

the chamber size is customized.

150*150*150mm ; 200*200*200mm; 300*300*300mm ;
400*400*400mm ; 500*500*500mm
Temperature control Digital 50 segments programmable
Max. vacuum level 7*10ˆ(-3)Pa
Heating element 1800 MoSi2 rods SiC rods resistance wire
Refractory material Alumina ceramic fiber
Thermal couple B type S type K type
Working voltage AC 110-480V 50-60Hz
Warranty 12 month (exclusive wearing part)
