Desktop Electrothermal Hot Air Circulating Drying Oven Industrial Laboratory Oven Drying ovens are used to remove moisture content from coatings and various substrates. The drying process occurs through a variety of laboratory applications including sterilization of materials and equipment, evaporation, temperature testing and incubating. The below drying ovens are designed for various needs and are offered in an array of sizes and temperature ranges, including customizable drying ovens.
* heating and drying ovens are available in a variety of sizes and configurations, ranging in size from 20Liters to 2000Liters, including bench- top and standard type.
* Wide temperature ranges and volume selection
* CE mark, ISO17025 calibration
| Internal Dimension (mm) | 400*500*500 | 500*600*750 | 700*800*900 | 800*1000*1000 | 1000*1000*1000 | |
| Overall Dimension (mm) | 750*880*850 | 800*950*1000 | 1100*1100*1300 | 1100*1450*1400 | 1300*1400*1400 | |
| Interior Volume | 100L | 225L | 500L | 800L | 1000L | |
| Parameter | Temperature Range |
A: Ambient ～+250 ℃ B: Ambient ～+400 ℃ C: Ambient ～+900 ℃ |
||||
| Temperature Fluctuation | ± 0.5 ℃ | |||||
| Temperature Deviation | ± 2.0 ℃ | |||||
| Heating Rate | 6 ℃ / min | |||||
| Heating Element | Nichrome heater | |||||
| Controller | Programmable color LCD touch screen controller | |||||
| Ethernet connection, PC Link | ||||||
| Temperature Sensor | PTR Platinum Resistance PT100Ω/MV A-class, accuracy 0.001℃ | |||||
| View Window Size(mm) | 120*150 | |||||
| Air Circulation | Centrifugal wind fan | |||||
| Safety Device |
Over-temperature Protection; Over-current Protection; Refrigerant High-pressure Protection; Earth leakage Protection |
|||||
| Material | Exterior Material | Steel Plate with protective coating | ||||
| Interior Material | SUS304 stainless steel | |||||
| Thermal Insulation | Polyurethane foam (Refractory brick) | |||||
| Observation Window | Interior lighting, double-layer thermo stability silicone rubber sealing | |||||
| Standard Configuration | 2 shelves | |||||
| Power Supply | 380V 50Hz | |||||
| Maximum Noise | 65 dBA | |||||
| Environmental Conditional | 5℃～+35 ℃ ≤85% RH | |||||
Work Room:
The internal material is 304 stainless steel, mirror surface, rust-proof to high and low temperature and moisture corrosion;
Nice ruggedness and long life.
Sample Shelf
SUS304 stainless steel punching sample shelf 2pcs;
Standard load of 50KGS for each layer of sample shelf;
The height of the shelf is adjustable and can be removed directly to facilitate the various sizes of test samples.
Conducive to the air circulation.
Special sample shelf can be customized
Castor
Install 4 castors for easily moving, and with brakes function. Castor height is adjustable.
