Box Type Furnace, Industrial Microwave Furnace Debindering Zirconia Blanks
The Microwave Box Type Furnace can be applied for industry sintering, while features of high heating efficiency, rapid heating speed and good heating uniformity makes it reliable for application.
The HY-XS6017 is suitable for debindering process of zirconia blanks under air atmosphere conditions with chamber volume of 3 liters.
| Parameters | ||
| Power | Voltage | 380V±10V 50Hz |
| Rated Power | 9KW | |
| Microwave System | Microwave Output Power | 0.10~5.60KW continuously adjustable |
| Microwave Frequency | 2.45GHz | |
| Microwave Leakage Prevention | microwave leakage intensity<2mW/cm2 | |
| Thermal Insulation System |
Tmax | 1700°C |
| Working Temperature | 0~1650°C | |
| Heating Space(L×W×H) | 160×160×120mm | |
| Temperature Control System |
Temperature Measurement Method | infrared thermometer |
| Temperature Measurement Range | 300°C~1800°C | |
| Temperature Control Precision | ±0.1% | |
| ControlSystem | Auto, Manual and Isothermal Controlling Mode, PLC+Touch Screen |
40 segments of programmable technical parameters, data storage and export, real-time curve data display, dynamic data display |
| Safety System | Magnetron Alarm | over temperature alarm |
| Furnace Door Protection Alarm | furnace door shutdown sensor | |
| Cooling System | Cooling Water Requirments | flow rate≥ 2m3/h,T≤35°C |
